Flexible and Durable Perforated Pipe for Oil Well

Flexible and Durable Perforated Pipe for Oil Well
Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well Flexible and Durable Perforated Pipe for Oil Well
Basic Information
Place of Origin: China
Brand Name: OASIS
Certification: ISO
Minimum Order Quantity: 10 Meter/Meters
Price: Negotiation
Packaging Details: Wooden cases or pallet or bundle or container,or according to clients' requirements
Delivery Time: Within 35 days
Payment Terms: L/C, T/T
Supply Ability: 6000 Meter/Meters per Month
Get Best Price Contact Now
Surface Treatment: Polished Special Pipe: API Pipe
Filter Rating: 85% Availability: In Stock
Temperature Resistance: High Heat Resistance: High
Connection Way: API Thread(STC,LTC,BTC) Or NUE, EUE Feature: Corrosion Resistance
Connection: Welding Rings, Thread Ends Usage: Water/oil Well Drilling
Durability: Long-lasting Pressure Resistance: High

Perforated Pipes



Products Description



OASIS has been offering the strong and durable perforated pipe products for 20 years. We are specialized in perforated pipes producing and exporting. Advanced production equipment, skilled workers, professional sale representatives and considerate after sale service contribute our high quality products and long term cooperation with our customers. "The best solution for industrial filtration" Perforated pipe, made of high quality carbon steel, stainless steel or aluminum steel, is also called perforated tube, perforated steel tube, perforated steel pipe or filter pipe. It has hot dip galvanized, electro galvanized or powder coated surface, including straight perforated pipe, spiral perforated pipe and perforated casing pipe. It is widely used for industrial filtration. Compared with other perforated pipes, our products have the following advantages:high strength, perfect recyclability and long service life.

Perforated casing pipe, mainly made of stainless or mild steel, is also called perforated casing tube. It is used as connection support to make easy flow of oil or gas to the wellbore and featured by the high strength, deformation resistance, smooth surface, easy installation and long service life. Punched holes are distributed in straight line or staggered forms, and the open area of staggered type pipe is larger than the straight type pipe.





Feature of perforated casing pipe

● High strength and deformation resistance.

● Smooth surface without burrs.

● Easy installation.

● Durable and long service life. Advantage of perforated casing pipe





Specification of perforated casing pipe

● Material: mild carbon steel, stainless steel, aluminum steel.

● Outside diameter: 1'' to 10''.

● Hole diameter: 0.375'' to 0.5''.

● Hole shape: round, square, slot.

● Hole distribution: straight line, staggered, spiral staggered.

● Open area: up to 65%





Application of perforated pipe

● Pulp mills.

● Silencer.

● Chemical processing and brewing industries.

● Oil or lube filtration industries.

● Sewage or purified water treatment





Specifications





尺寸

Pipe Size

(inch)

孔数/英尺

Holes per feet

孔径

Size of Hole

(inch)

开孔率/英尺

Perforated Area per feet
3/4” 78 3/16” 2.15
1” 54 5/16” 4.14
1-1/4” 66 5/16” 5.06
1-1/2” 78 5/16” 5.06
2-1/16” 78 5/16” 5.98
2-3/8” 90 3/8” 9.94
2-7/8” 102 3/8” 11.26
3-1/2” 126 3/8” 13.91
4” 138 3/8” 15.24
4-1-2” 150 3/8” 16.56
5” 162 3/8” 17.88
5-1-2” 174 3/8” 19.21
6-5/8” 186 3/8” 20.53
7” 222 3/8” 24.51
9-5/8” 294 3/8” 32.46







More Details

Flexible and Durable Perforated Pipe for Oil Well 0

Flexible and Durable Perforated Pipe for Oil Well 1

Flexible and Durable Perforated Pipe for Oil Well 2





Related Products



      Flexible and Durable Perforated Pipe for Oil Well 3











Advanced technology, Strict inspection process:

Oasis Oil Tools co.,ltd has 20 years experience in Water Filter Mesh Screens/Water Well Sand Filters, we strive for technical innovations to improve quality of products.Our products not only have the features of trustworthy quality, safety and energy save but also beautiful appearance and low maintanemance.

Small profits but quick turnover:

Our Production will offer you a relatively and reasonable lower price, which means our customer can get more profite with a cheap price.

Premium and comprehensive sale system:

With a comprehensive sale system including before sales service, in-sale service and after sale service, we have won a good reputation at home and abroad. Also it is a important reason why so many customer to choose us.

Please contact with us for more details.

Our techinical team will give you the best choice.
