Place of Origin: | China |
---|---|
Brand Name: | OASIS |
Certification: | ISO |
Minimum Order Quantity: | 10 Meter/Meters |
Price: | Negotiation |
Packaging Details: | Wooden cases or pallet or bundle or container,or according to clients' requirements |
Delivery Time: | Within 35 days |
Payment Terms: | L/C, T/T |
Supply Ability: | 6000 Meter/Meters per Month |
Material: | Stainless Steel Wire | Hole Shape: | Vee Shaped |
---|---|---|---|
Usage: | Liquid Filter | Treatment: | Polished |
Weave Style: | Plain Weave | Feature: | Corrosion Resistance |
Quality: | Excellent | Durability: | Long-lasting |
Marking: | As Per The Clients' Requirements | Material Details: | Stainless Steel 304 316L, Carbon Steel |
Product Description
Wire wrapped screen is widely used throughout the world for water, oil, and gas wells, and is the dominant screen type used in the water well industry. Wire wrapped screen is made by winding cold-rolled wire, approximately triangular in cross section, around a circular array of the longitudinal rods. The wire is attached to the rods by welding, producing rigid one-piece units having high strength characteristics at minimum weights. Wire wrapped screens are manufactured by spacing successive turns of the outer wire to produce the desired slot size. All slots should be clean and free of burrs and cuttings.Each slot opening between adjacent wires is V-shaped, from the special shape of wire used to form the screen surface. The V-shaped openings designed to be nonclogging, are narrowest at the outer face and widen inwardly.
The wire wrapped screen has 3 outstanding advantages.First, Production process continuity: V-shaped profile wires creating slots which enlarge inwardly and therefore avoid clogging and minimize downtime.Second,Low maintenance costs: Separation at the screen surface which can easily cleaned by scraping or back washing. And Low operational costs: Large open area with an effective flow, high yield and a low pressure drop (dP).
Our wire-wrap screens are a versatile, cost effective and viable sand control option in a variety of well environments. What you will receive is a balance between effective sand control and long term well productivity at an affordable budget.
Wire-wrap screens can be fully customized to meet any specific well application. They feature strong assemblies, are resistant to erosion, and cannot be plugged by fines or produced solids.
An exclusive slip-ring design isolates the wire-wrap jacket from mechanical loads applied to the screen assembly (i.e. compression, tension, or torque), maintaining efficient sand control.
Specifications
Wire Width(mm) | 1.2 | 1.5 | 2 | 2.2 | 3 | 3 | 3.2 | 4 | 4 |
Wire Height(mm) | 2.2 | 2.5 | 3 | 4.5 | 5 | 6 | 6.5 | 7 | 7.5 |
Slot(mm) | 0.02mm~15mm |
Advanced technology, Strict inspection process:
Oasis Oil Tools co.,ltd has 20 years experience in Water Filter Mesh Screens/Water Well Sand Filters, we strive for technical innovations to improve quality of products.Our products not only have the features of trustworthy quality, safety and energy save but also beautiful appearance and low maintanemance.
Small profits but quick turnover:
Our Production will offer you a relatively and reasonable lower price, which means our customer can get more profite with a cheap price.
Premium and comprehensive sale system:
With a comprehensive sale system including before sales service, in-sale service and after sale service, we have won a good reputation at home and abroad. Also it is a important reason why so many customer to choose us.
Please contact with us for more details.
Our techinical team will give you the best choice.
