Basic Information

Place of Origin:	China
Brand Name:	OASIS
Certification:	ISO

Minimum Order Quantity:	10 Meter/Meters
Price:	Negotiation
Packaging Details:	Wooden cases or pallet or bundle or container,or according to clients' requirements
Delivery Time:	Within 35 days
Payment Terms:	L/C, T/T
Supply Ability:	6000 Meter/Meters per Month

Get Best Price Contact Now

Profile Wire:	1*2mm VEE Wire	Unit Length:	Up To 6m
Surface Treatment:	Galvanized Or Painted	Durability:	Long-lasting
Support Rod:	2.3mm-5mm	Wire Size:	3*4.6mm Vee Shaped
Grade:	316L	Color:	Silver
Filtering Slot:	25 µm	Quality:	Excellent
Tube Chip Color:	Blue	Slot Shape:	V Shape
Feature:	High Strength	Wire Feature:	Wedge Shape

Product Description

Wedge wire screen is a metal mesh component that is widely used in screening, filtration, dehydration, and desliming operations for screening and filtration. It has high strength, stiffness and load-bearing capacity, and can be made into rigid screening filters in various shapes.

The wedge-shaped mesh consists of a surface profile and a support profile. The surface profile (usually a V-shaped wire) is wrapped and welded to the support profile. The distance between the surface profiles is controlled very precisely because it forms the groove through which the filtrate flows. The direction of flow is determined by the position of the V-shaped line (surface profile) relative to the support profile. Wedge-shaped wire mesh is outflow to inflow or inflow to outflow.

Its homogeneous filter groove and high precision guarantee effective retention of the filter media.Compared to other screens, wedge-shaped wire mesh has a larger flow area.

The tiny gap between the wedge-shaped wires forms a smooth wedge-shaped cross-section, ensuring no dead angles, excellent clogging resistance, and easy backwashing (blow-washing).

It has high mechanical strength and can withstand high pressure drops.

It is made of high-quality stainless steel wire (SUS304 and 316L), which has strong corrosion resistance and high temperature resistance, and can fully adapt to various harsh environments

It adapts to different forms of fluid directions, and has high strength, high flow and high pressure resistance.

It maintains a stable filtration rating, is reusable and works reliably.

OASIS wedge screen adopts international advanced welding technology, which has considerable advantages in surface finish, gap uniformity, product quality, etc., so as to ensure that our products perform better and are more efficient in use!

Specifications

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 0
More Details

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 1

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 2

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 3

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 4

wire wrapped screens are used to effectively filter fine particles for improved long-lasting performance SS304 5

FAQ

What are the features and benefits of wedge wire screens?

1.High Strength: Our wedge wire adopts contour welding technology and provides high strength for the whole structure.

2.Maximum Flow Rate: Wedge wire enjoys a relatively small resistance and delivers a high flow rate. Therefore, its flow volume is greatly increased compared with plastic filter elements with a similar size.

3.Anti-Clogging Slot: Wedge wire forms V-shaped openings with narrow opening outside and wide opening inside. Therefore, large particles are kept outside the screen and small particles pass through the narrow opening and enter the screen.

4.Great Adaptability to Temperature Changes: Compared with ordinary plastic filter elements, wedge wire performs better adaptability to temperature changes and is applied to environments with great temperature changes.

5.Excellent Corrosion Resistance: Thanks to the properties of the stainless steel, our wedge wire presents excellent corrosion resistance performance in various acid and alkaline environments like recycled caustic soda, hydrochloric acid and sulfuric acid. Therefore, our wedge wire can work economically and safely in filters that apply to various environments.

6.Custom Slot Size: Customers employ various filters and filtering mediums for filtration, therefore, they will have different requirements for slot size. Our screens are continuously welded by special welding equipment, therefore, the slot size can be customized to achieve high precision filtration. In this way, we can meet the needs of different customers without additional costs.

How about your sales service?

Market promotion support and best after sales service will be offered to every customer.

What payment term do you accept?

T/T ,L/C at sight, Western Union, and other mainstream payment term.

How about the MOQ?

MOQ according to different product, sometimes MOQ decided by customer.
